Diplexer Antenna

Frequency Range : 850 MHz to 2500 MHz
Part Number : SSPD-113-49
GSM/WLAN Diplexer Antenna

SSPD-113-49:  Diplexer operates at 850 to 1990 MHz and 2400 to 2500 MHz,  allowing simultaneous use of a single antenna between GSM and wireless LAN type devices. The diplexer exhibits very low insertion loss and has excellent isolation between frequency bands. Hermetically sealed. Can be paired with Sensor Systems telemetry and wireless antennas such as the S65-5366-715 and the S65-5366-716.

FEDERAL & MILITARY SPECS: IEEE 802.11 b/g, GSM (Global System for Mobile Communications), MIL-STD-810, MIL-HDBK-5400, MIL-E-5272.

Click Here for Data Sheet

SSPD-113-49_Specs

Description

SSPD-113-49:  Diplexer operates at 850 to 1990 MHz and 2400 to 2500 MHz,  allowing simultaneous use of a single antenna between GSM and wireless LAN type devices. The diplexer exhibits very low insertion loss and has excellent isolation between frequency bands. Hermetically sealed. Can be paired with Sensor Systems telemetry and wireless antennas such as the S65-5366-715 and the S65-5366-716.

FEDERAL & MILITARY SPECS: IEEE 802.11 b/g, GSM (Global System for Mobile Communications), MIL-STD-810, MIL-HDBK-5400, MIL-E-5272.

Click Here for Data Sheet

Specifications

SSPD-113-49_Specs

Outline Drawings
Performance
